Product Details:
Payment & Shipping Terms:
|
| Cooling Method: | Air Cooling | Applicable Material: | Stainless Steel, Carbon Steel, Aluminum, Metal |
|---|---|---|---|
| Product Train: | Video Technical Support, Online Support | Cleaning Type: | Fiber Laser |
| Condition: | 2021 New | Laser Wavelength: | 1064nm |
| Highlight: | Handheld laser cleaning machine 100w,1064nm Handheld Laser Cleaning Machine,100W handheld laser cleaner |
||
Machine application:
1. Metal or glass surface coating removal, rapid removal of paint
2. Quick rust removal and various oxides
3. Remove grease, resin, gum, dust, stains, and produce residue
4. Roughening of metal surface
| Model | Handheld Laser Cleaning Machine | ||||
| Cleaning Case | |||||
| Substrate Material | Cast iron | Carbon steel | Stainless steel | Die steel gear | Aluminum |
| Surface | Severe rust (0.08mm) | Moderate rust (0.05mm) | Greasy dirt Slight rust |
Moderate greasy Iron residue |
Oxide Dirty surface |
| Effective DOF (mm) | 8 | ||||
| Normal Speed (mm²/s) | 2000 | 1800 | 2000 | 1500 | 1500 |
| High Speed (mm²/s) | 3000 | 2400 | 3000 | 2300 | 2000 |
| Effect | Surface cleaned without harming the substrate material | ||||
| The above data is for reference only, practical data will vary based on the complexity of the application. | |||||
| ELECTRICAL RATINGS | |||||
| Supply Voltage | 220 ± 10 AC | ||||
| Current Consumption | 5 ± 1 A | ||||
| OTHER SPECIFICATIONS | |||||
| Operating Temperature | 0 to +40℃ | ||||
| Storage Temperature | -10 to +60℃ | ||||
| Humidity | 10 to 96% | ||||
| Cooling Method | Air Cooling | ||||
| Warm Up Time | 10s (Start operation after the alarm sound) | ||||
Before welding or bonding, remove paint, rust, grease, weld oxide, residue treatment
Mold cleaning, such as tire mold, electronic mold, food mold
After the production of precision parts, oil removal
Quick cleaning of nuclear power unit maintenance
Aerospace weapons, processes for the manufacture or maintenance of ships, removal of paint, rust removal
Metal surface cleaning in narrow space
Cultural relics cleaning, rock cleaning, exterior cleaning of buildings.
