Product Details:
Payment & Shipping Terms:
|
| Certification: | CE | Working Area: | 6090 |
|---|---|---|---|
| Package: | Wooden Case | Ink Color: | CMYKWW |
| Brand: | Maxwave | Warranty: | 1 Year |
| High Light: | 60Hz Tile Printing Machine,G5 Head Tile Printing Machine,G5 digital tile printing machine |
||
CE G5 Head UV 60Hz Tile Printing Machine Anti Collision Sensor
UV LED High Resolution Industrial Ink Jet Printer Ceramic Tile Bathroom Tile Printing
Parameter
| Product Model | MW-UP6090 |
| Printhead Technology | Drop-on demand piezo eletric |
| Printhead Control | Printhead voltage is software adjustable |
| Printhead Type | RICOH GEN5 |
| Printhead Number | 2/3/4/5/8 |
| Ink Characteristics | UV Curing Ink |
| Ink Reservoirs | Refillable on the fly while printing/1000ml per color |
| Lamp | UV LED lamp |
| Color Control | ICC based color, curves and density adjustment |
| Printhead Aarrangement | C M Y K LC LM W optional |
| Cleaning System | Positive Pressure Cleaning |
| Guide Rail | Taiwan HIWIN |
| Working Table | 6-section Vacuum Sucking table |
| Printing Size | 2000*3000mm |
| Print Interface | USB2.0 |
| Media Thickness | 0-100mm, higher can be customized |
| Print Resolution |
720*360dpi, 720*720dpi, 360*1080dpi, 720*1080dpi, 720*1440dpi, 1440*1440dpi |
| Printing Speed | 15sqm/h-30sqm/h |
| Life of Printed Image | 3 years (outdoor),10years (indoor) |
| File Format | TIFF, JPEG, Postscript, EPS, PDF etc. |
| RIP Software | UltraPrint/ Photoprint/ Onyx |
| Power Supply | 220V 50/ 60Hz (10%) |
| Operation Environment | Temperature 20 to 28℃, Humidity 40% to 60% |
| Warranty | 13 months exclude the consumables |
Features
Japanese imported Ricoh GEN5 head for industrial production
CMYK W W printing 3D embossed effect with high quality and high speed
Auto height detection technology to detect print media thickness automatically
Automatic anti-static design to avoid dust ink drops flying Advanced printhead anti-crash system to avoid the risk of a collision between printer carriage and material
Computer stand to support connection with printer easily Big ink tank containeously working, fill ink without stop Ink alarm system to provide sign for refill the ink Solid steel body structure and customized design beam for stable working
UV LED lamp made in Korea for long life working more than 30000hrs
1. What materials can uv printer print on ?
printers are multi-functional printers: it can print on any materials such as phone case, leather, wood, plastic, acrylic, pen, golf ball, metal, ceramic, glass, textile and fabrics etc...
2. Can LED UV printer print embossing effect?
Yes, it can print embossing effect, for further information or samples pics, please contact our representative salesman.
3.Does it must be sprayed a pre-coating?
some material need pre-coating , such as metal, glass,etc
4. How can we start to use the printer?
We will send the manual and teaching video with the package of the printer.
Before use the machine,please read the manual and watch the teaching video and operate strictly as the instructions.
We will also offer excellent service by providing free technical support online.
5. What about the warranty?
Our factory provide one year warranty: any parts (except print head,ink pump and ink cartridges) questions on normal use, will provide new ones within one year(not include shipping cost). Beyond one year, only charge at cost.
6. what’s the printing cost?
Usually,1 square meters need cost about $1.
Printing cost is very low.
7. how can i adjust the print height?
Our printer installs infrared sensor so the printer can detect the height of printing objects automatically.
8. where can i buy the spare parts and inks?
Our factory also provide spare parts and inks,you can buy from our factory directly or other suppliers in your local market.
9. what about maintenance of the printer?
About maintenance,we suggest to power on the printer once a day.
If you don’t use the printer more than 3 days, please clean the print head with cleaning liquid and put in the protective cartridges on the printer (protective cartridges are specially used for protect print head)
